  • Official FMS Atlas 4x4 1/10 Scale 4WD Crawler Discussion Thread

    Atlas 4x4 1/10 Scale 4WD Crawler - RTR from FMS



    Click image for larger version  Name:	fms-atlas-4x4-yellow-1-10-scale-4wd-crawler-rtr-motion-rc-34631850164409.jpg Views:	0 Size:	238.0 KB ID:	378650








    Version Info: This truck is delivered as "RTR", however does require 4 x AA batteries for the transmitter, a 2S 5000mAh LiPo with XT60 connector, and suitable LiPo battery charger (see Requires below for details).

    The 1:10 Atlas 4WD crawler is perfect for hardcore crawling action and features a capable, heavy duty four-link suspension system coupled with a versatile two-speed transmission that can be remotely shifted on the fly from the transmitter. The lightweight, durable factory-painted polycarbonate bodyshell is available in three colors and conveniently designed to tilt forward, allowing easy access for battery installation/removal and maintenance. Additional realism is provided with details such as spotlights, tow hooks, muffler, fire extinguisher, and more.

    Enjoy an impressive crawling experience by combining the versatile, go-anywhere fun of the FMS Atlas with Motion RC’s parts and technical support, industry-leading customer service and product selection for a package that cannot be beat!
    Convenient Body Mounting System

    The Atlas features a simple and convenient tilt-forward body mount system that allows easy access to battery and electronics.
    120mm AT Tires

    The grippy all-terrain tires used on the Atlas deliver the perfect combination of traction and sidewall compliance to master the most challenging climbs or traverse difficult obstacles.
    Metal Chassis with Four-Link Suspension

    Metal frame rails with a four-link suspension deliver superior climbing ability and off-road performance.
    Composite Roll Cage

    A sturdy composite nylon roll cage offers protection for the body in the event of a rollover, and the functional spare tire provides a scale look and a practical spare.
    35T 550 Brushed Motor

    The specifically designed brushed motor delivers the torque and smoothness required for a top-notch chassis to perform at its best!
    Personalized Stickers

    Make the Atlas your own with various included decorative sticker options.
    Features:
    • Assembled and Ready-to-Run (additional items required)
    • Complete ball bearings
    • 100% metal-geared transmission
    • Composite nylon roll cage
    • Metal chassis frame rails
    • Four-link suspension
    • Convenient tilt-up body mounting system
    • Factory-painted and decorated body
    • Includes addition stickers for personalization
    • 120mm All-terrain crawler tires
    • Powerful 35T 550 brushed crawler motor
    • Reliable 2.4 GHz radio system
    Includes:
    • FMS Atlas 4x4 Yellow 1/10 Scale 4WD Crawler - RTR
    • 2.4GHz transmitter
    • 2-in-1 receiver / 40A ESC (installed)
    • 550 brushed motor (installed)
    • 15kg metal digital servo(installed)
    • Product manual
    Requires:Product Specifications:

    AGE LEVEL : 14 and up
    SKILL LEVEL : Beginner
    BUILD TIME : Less than 15 minutes
    Model Scale 1/10
    Length 537mm / 20.9in
    Width 241mm / 9.4in
    Height 247mm / 9.6in
    Weight (No Battery) 2,536g / 91oz
    Wheelbase 340mm / 13.2in
    Ground Clearance 79mm / 3.1in
    Body Polycarbonate, factory painted
    Chassis Metal/composite ladder-type
    Drivetrain 4WD
    Wheel Size (Diameter x Width) N/A
    Wheel Hex Size 12mm
    Tire Tread All-terrain
    Bushing Material N/A
    Suspension Four-link with dampers
    Shock Type Oil-filled, coil-over
    Transmission 4WD shaft-driven
    Gear Pitch N/A
    Internal Gear Ratio N/A
    Final Drive Ratio N/A
    Pinion N/A
    Spur Gear N/A
    Differential No
    Ball Bearings Yes
    Brakes Electronic
    Electronic Speed Control Brushed 2-in-1 RX/ESC (included)
    Motor 550-size brushed
    Battery 2S 7.4V LiPo (not included)
    Max Battery Dimensions (L x W x H) N/A
    Servos 1
    Radio 4 channel (included)
    Lights Yes
    Sound No
    Water Resistant Yes
    Skill Level Beginner
    Assembly Time Less than 15 minutes
    Recommended Environment Outdoors

  • #2
    good post...got mine a couple weeks ago....any solution for the axle pins yet?

    Comment


    • #3
      I make my own from identical diameter of drill blank material.

      Comment


      • #4
        Wondering if anyone else has broke a panhard mount? If you have where did you get a replacement

        Thanks
