Version Info: This is the 6S version of the 64mm L-15. This model comes with a brushless 2949-2300Kv outrunner motor and a 50A Brushless ESC with XT60 connector. The 6S version accepts a 1800 - 2600 mAh 6S 22.2V LiPo battery. The 6S version also includes CNC-machined aluminum, shock absorbing struts while the 4S version has standard fixed landing gear with plastic scale parts. The picture above is actually showing the 4S landing gear.
The Hongdu L-15 Falcon, also known as the JL-10, is a supersonic trainer and light combat aircraft developed by Hongdu Aviation Industry Corporation (HAIC). It is utilized by the People's Liberation Army Air Force (PLAAF) as a lead-in fighter trainer (LIFT).
The overall planform, scale shape and details of the L-15 are expertly captured in this 64mm EDF Jet from Freewing. The scale armament utilizes Freewing’s latest sliding attachment method, making it a breeze to install or remove these scale details, and with its overall simplistic design, you can be flying in as little as 30 minutes with the PNP version.
Freewing EG01 3/6-axis Gyro The L-15 is equipped with the new Freewing EG01 3/6-axis Gyro, which is user configurable through a mobile application. |
6S Power System This version of the L-15 includes a 2949-2300Kv outrunner motor and 50A ESC designed to work on a 6S 1800-2600mAh LiPo battery. |
Removable Scale Missile Details The L-15 includes two PL-8 and PL-12 scale missles that add scale detail and are quickly installed and removed. |
Full Flying Horizontal Stabilizers The L-15 includes a full flying horizontal stabilizer design, just like the full size counterpart. |
12-Blade EDF Power System The L-15 includes the latest generation 64mm, 12-blade EDF unit for efficient and powerful performance across the entire flight spectrum. |
8 Pre-Installed 9g Servos With 8 pre-installed 9g servos, the L-15 features a full setup including flaps, ailerons, elevators, rudder and nose gear steering control. |
- CNC-machined aluminum, shock absorbing struts (on the 6S version)
- Freewing EG01 3/6 Axis Gyro
- 12-Blade EDF with 2949-2300Kv Brushless Motor
- 50 Amp Electronic Speed Controller
- 6S LiPo capability for high performance flight
- Scale details, including armament, pilot and landing gear
- Full flying horizontal stabilizers
- Complete aileron, flap, elevator, rudder and nose gear control
- 8x 9g servos pre-installed
- Freewing L-15 JL-10 Falcon 6S 64mm EDF Jet - PNP
- Motor, EDF, ESC, and servos included and installed
- Instruction manual
- 5 Channel radio - select a minimum 5 channel radio from our Radio Collection
- 5 Channel receiver - select a minimum 5 channel receiver from our Receiver Collection
- TWO 6 Cell 22.2V 1800 - 2600 mAh LiPo Batteries with XT60 Connector in series - we recommend TWO of the Admiral 2200mAh 3S 11.1V 35C LiPo Battery with XT60 Connector
- 2 to 1 Series adapter - we recommend the BenchCraft XT60 2 to 1 Series Adapter
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
AGE LEVEL :14 and up
SKILL LEVEL :Intermediate
BUILD TIME :30 minutes
Wingspan | 760mm / 29.9in |
Length | 970mm / 38.2in |
Weight | 910g / 32.09oz |
Power System | 2949-2300Kv brushless outrunner motor |
Speed Control | 50A, XT60 Connector |
Propeller / EDF | 64mm 12-Blade EDF |
Servos |
|
Landing Gear | CNC-machined aluminum, shock absorbing struts |
Required Battery | 6S 22.2V 1600mAh to 2600Ah LiPo with XT60 connector (required) |
Required Radio | 5+ Channel radio |
Rudder | Yes |
Flaps | Yes |
Ailerons | Yes |
Lights | No |
Hinge Type | Nylon hinges on all control surfaces |
Material | EPO Foam |
Skill Level | Intermediate |
Build Time | 30 Minutes |
Recommended Environment | Outdoors |
