Official Freewing JAS 39 Gripen 80mm EDF Jet

[Cfreuen20]

I went ahead and bought an aura 8 for this. After a couple hours of unsuccessfully trying to configure it, I'm still not there.

Does anyone have an aura 8 config file for this plane?

[Airguardian]

I' have an Aura 12 but haven't installed it anywhere yet, sorry.

[xviper]

I went ahead and bought an aura 8 for this. After a couple hours of unsuccessfully trying to configure it, I'm still not there.

Does anyone have an aura 8 config file for this plane?

There are only a couple of users on this forum who are well versed on the Aura 8 and they love them. Hopefully they will see this and volunteer to help you. They always rave about the Aura 8 but I've never seen any of them volunteer to help others get them set up.
Personally, when I get a Flex airplane with an Aura 8 in it, the first thing I do is yank it out and try to sell them to someone, anyone and for a few bucks. After my first attempt at flying a plane with the Aura 8 in it that was preprogrammed, I hated it the way it flew. After trying (what seemed like forever and with no success) to change the parameters, I gave up and removed it in favor of a simpler, cheaper gyro like the HobbyEagle basic gyro. That's what I have in my Gripen and it works flawlessly. On occasion when I could not sell the Aura, I tie it to a rock and throw it in the lake.

[SanExup]

xviper does it actually land in the lake or auto level and skip across the surface?

[xviper]

xviper does it actually land in the lake or auto level and skip across the surface?

I used a flat-ish rock, so it managed to skip about 3 times before it sank. The Aura8 has very high water resistence, so it doesn't skip very well. The recovery mode works like crap. It should have skimmed just over the water and landed on the opposite bank. There was a guy who almost jumped in the row boat and went out to find it. I told him not to bother, I had more planes coming from Flex and I'd sell them to him for 20 bucks each.

[WVfoambuster]

Finished painting my gripen today. Waiting decals and weather.

[Airguardian]

w00t !

[Evan D]

It was Gripen day today for me. I took out my three and flew them all back to back. Great day.


I need to buy a couple more.

[SanExup]

TV and non TV? Stock fans or upgrades?

[Evan D]

Yes and both. The Urugauyan has TV and a Jetfan/HET 8S set up. The next is stock non TV 6S and the rear is the spare I've had and decided to put together and is stock 6S with TV. I was asked just how many do I need. I said I think five

[SanExup]

You're part way there! Are tou pleased with the stock TV performance in comparison to the Uruguayan setup?

[Evan D]

Very much so. If I had to have only one the stock TV would be the one I would have. I thought it would have significantly less power from the non TV but it doesn't. I flew the two 6S with Power Hobby 5000 100C that weigh 555-575g and fly for 4:30 on the non-TV and 4:10 for the TV so I am on the throttle a little more. The 8S one uses the same battery plus a 250g 2S and flys for 4:10.

Both the non TV and 8S TV needed quite a bit of weight in the tail to get the balance I like of about 25mm behind the marks. The 6S TV balanced easily at 25mm with no extra weight. That said I added about 25g in the tail cone to allow me to go to about 35mm OR use a slightly heavier 5200 (at 25mm) that I may use at some point.

[Markpawlawski]

I have a Freewing Mig29 with twin 80 mm inducted fans. What’s the max C rating on the battery that I can use for this plane does anyone know

[Evan D]

There is no standard for C ratings if you do some reading. The thing is to try a battery and if it performs to your satisfaction get more. As an example I’ve had 25C ones that work great I’m these 100A 80mm fans but I’ve had 50’s and 60’s that puff. Right now I’m using ones that have 100 on the label and even though they work great they work about as my 50C do.

the Gripen needs light batteries to balance so think of it as a trade off between mAh, C, and weight. What are you using in your MiG?

[Piffis]

So, I've read a lot of the pages in this thread, but must admit haven't managed to go over all 111. 😏

I'm a rookie. But love the looks of these scale RC aircraft. Being a Swede it's extra fun to see a Gripen model.
I've flown a bit of RC helicopter before, nothing advanced.
I bought myself a high-wing trainer, NX10 and a Simulator. The trainer is a Spektrum BNF with SAFE/AS3X feature + panic button. This is nice to have as a rookie.

My goal is to fly these scale jets and I was thinking of making Gripen the first in my collection.

I've got a few questions that are likely so basic that they were never asked in this thread as you all seem to be very experienced.

1. To get the equivalent to SAFE/AS3X I understand I need a gyro, or a Spektrum received with SAFE/AS3X. According to the FW webpage 7 channel is required. So could I get the Spektrum AR8360T (8 ch with SAFE/AS3X) and use it similar to my trainer?
   If this receiver is ok, are there a lot of setting to be made? The trainer just works out the box.
2. I'd like telemetry in order to be notified when the batteries go low. The receiver AR8360T seem to support it, but would I then need to replace the ESC as well?
3. Do people generally buy spares to keep on stock? How long are these models typically available? If I don't get spares now, will I typically be in trouble in a few months when I crash? (if not earlier 😂)
4. As I don't have any experience with EDF, my goal is to cruise and I'm happy if I land safely. So no TV or so for me at this moment.
   Is the Gripen a different beast? Is it extremely difficult to fly even compared to a "standard EDF" and I should re-think and buy another model as an entry model?

OMG, I see Freewing B2, I see Freewing F16, I see... this will be an expensive hobby.. especially if not landing safe 😣

Thank you

[Evan D]

Both AS3X and SAFE are Spektrum trade marked terms. In general AS3X is a gyro system and SAFE is a self leveling system.

Most FreeWing aircraft have a mixing board in the plane to enable them to use simpler 6 channels system for the basic aircraft. In some cases more are needed like the F-14 has wing sweep, the F-104 and Eurofighter have air brakes. Many people bypass these mixing boards to have additional functions on their aircraft and that usually means extra channels. A easy example is many separate the steering from the board to be able to have separate trim and rates for steering, extra channel. Also if you have a gyro or self leveling you may need additional cannels for those. For the Gripen if you want TV you need two extra channels for that too. To confuse it a bit some Spektrum receivers have hidden channels in them for things like AS3X and SAFE. If you go that route be very specific in your questions about the transmitter, receiver and set up you are wanting to do.

Spektum also has SMART. It's only as smart as your system is and you know how to use it. The ESCs that FW uses are not SMART.

Spares for "these models"... FreeWing keeps their models and spares around for longer than any other brand in my opinion. I have seen some brands discontinue something 6 months after release. I've seen THAT brand also discontinue and then rerelease a model. My opinion is if you like something get a spare (maybe a kit+) as it usually won't go down in price and you don't know when it'll be discontinued. If, in the future you decide not to build that spare it seems there are others that will want it because, well, it was a good plane....

I do not suggest the Gripen as a first EDF since it is a bit more advanced to set up and a bit more to fly. If you have the standard plane experience and the money the 70-80mm size is a great starting point. My suggestion is the 80mm F-86 (scale) or Avanti (sport jet) for a first EDF. But I do suggest making sure you are comfortable with a prop plane first. And ask for help where you fly when it come time to maiden it.

When I got into planes at a very early age my have to have was the Fokker DR-1. I built paper ones, free flight rubber band ones, free flight and control line small glow ones. I knew when I got into RC in the late 1960's that was my goal. I bought the kit I knew I would want to fly in 1976 but stashed it away and built it over 1979/1980. I didn't fly it until a year or two after that even. But making sure I could fly it and only flying it on days the weather was good means I still have that cherished plane. It's had three or four different glow power systems and is now electric but I still have it and I still fly it. Get from that any moral you want.

Welcome to the forums.

[jasmith41]

Evan, have you ever heard of these ar637ta receivers going dead afgter updating them and resetting them to factory defaults...?

I had 3 of them go dead on me. Spares from planes, but wanted to update and unlock them so i could use them in other planes...

Any thoughts?

Spektrum is clueless on the issue. I'm sending all three of them back to them to try to figure it out...

[jasmith41]

Evan, have you ever heard of these ar637ta receivers going dead after updating them and resetting them to factory defaults...?

I had 3 of them go dead on me. Spares from planes, but wanted to update and unlock them so i could use them in other planes...

Any thoughts?

Spektrum is clueless on the issue. I'm sending all three of them back to them to try to figure it out...

[Evan D]

I'm not the one to ask. I mostly use Orange and I think the only one of those I have is in my V1200 and I never updated it. Sorry.

Evan, have you ever heard of these ar637ta receivers going dead afgter updating them and resetting them to factory defaults...?

I had 3 of them go dead on me. Spares from planes, but wanted to update and unlock them so i could use them in other planes...

Any thoughts?

Spektrum is clueless on the issue. I'm sending all three of them back to them to try to figure it out...

[kallend]

Evan, have you ever heard of these ar637ta receivers going dead after updating them and resetting them to factory defaults...?

I had 3 of them go dead on me. Spares from planes, but wanted to update and unlock them so i could use them in other planes...

Any thoughts?

Spektrum is clueless on the issue. I'm sending all three of them back to them to try to figure it out...

Suggest you look at flightengr's blog on RCGroups. He deals extensively with the unlocking issue. I unlocked and reprogrammed an AR637TA using his method and it works fine.

The probablity that you have three independently defective receivers taken from different planes is fairly remote. The common factor would seem to be the individual who attempted to unlock and reset them.
