Official Freewing 80mm EDF F-86 Sabre Thread

[Sheriffjohn]

I would like some opinions about how this F-86 flies compared to a few of the newer FW Jets. I had a F-86 when it first came out. It was my first EDF and I had issues with landing and went through a few nose LG and many repairs to the front end until one day I crashed. I've kept all the parts, less the foam. I went back to propeller planes for a few years. I now have an Avanti S and a F-18.

Would I still enjoy the FW F-86 or should I put my $$ into a later model EDF?

Thanks

SJ

[Captain Moron]

The F 86 is my favourite Freewing EDF .Easy to fly take offs and landings are a doddle .In my opionion this one of the easiest jets to fly along with the 90mm Venom and looks just great in the air

[Mark 2]

I would like some opinions about how this F-86 flies compared to a few of the newer FW Jets. I had a F-86 when it first came out. It was my first EDF and I had issues with landing and went through a few nose LG and many repairs to the front end until one day I crashed. I've kept all the parts, less the foam. I went back to propeller planes for a few years. I now have an Avanti S and a F-18.

Would I still enjoy the FW F-86 or should I put my $$ into a later model EDF?

Thanks

SJ

I love the looks and sound of the F86 but I find my BAe Hawk has become my go to jet now, it takes the same batteries that I use in the Sabre but just seems to have better performance and slightly longer flight times, and the Red Arrows paint scheme is easier to see against the grey cloudy skies we usually get here.

[Captain Moron]

Yes ,the Freewing Hawk is also up there with the F 86 and Venom .Mmmm so is the F16, F 35 the Me 262 and now the Albatross L 39 .In fact any Freewing EDF

[Kmot]

Hey everyone,

My F-86 is all together and I just tested the "tail sit" balance that I have read about. I am using a 4000 60C battery and it is placed up against the plywood plate securing the ESC.

I can rotate the plane so that the tail sits down, and it stays. If I touch the nose very lightly, it will rotate back onto the nose wheel. This is the desired balance, correct? It's ready to fly?

[Race 22 Crew]

Sounds right according to the different post. You can always make it a little more nose heavy for the first couple flights and move it back later. Tail heavy planes many times don’t survive that first flight. Good luck, they fly great. Check your main gear and make sure they are firmly glued in.

[John Bergsmith]

Hey everyone,

My F-86 is all together and I just tested the "tail sit" balance that I have read about. I am using a 4000 60C battery and it is placed up against the plywood plate securing the ESC.

I can rotate the plane so that the tail sits down, and it stays. If I touch the nose very lightly, it will rotate back onto the nose wheel. This is the desired balance, correct? It's ready to fly?

I balanced my sons F-86 using this method and it makes it a totally different airplane to fly. Basically if you push the tail down it should stay down, raise the tail up 1" and it should fall on the nose wheel. Using an Admiral 6s 5000mah battery it's basically all the way back against the foam bulkhead.

Have fun!

[Kmot]

Thanks fella's!

[Oxotnik]

I balanced my sons F-86 using this method and it makes it a totally different airplane to fly. Basically if you push the tail down it should stay down, raise the tail up 1" and it should fall on the nose wheel. Using an Admiral 6s 5000mah battery it's basically all the way back against the foam bulkhead.

Have fun!

During my flight this past Saturday, I was using a heavier battery, and I wasn't able to get the tail to stay down. Almost, but not quite. There was no headwind for take off and I was on a grass field. I was beginning to get worried that I wouldn't be able to rotate, when she finally rotated and eased into the air. You definitely don't want to be too nose heavy, if flying off of grass, on a calm day.

[timmybeetle]

Hey everyone,

I can rotate the plane so that the tail sits down, and it stays. If I touch the nose very lightly, it will rotate back onto the nose wheel. This is the desired balance, correct? It's ready to fly?

Interesting to read this, so my question regarding this balance method ??? is it also usable for other EDF's......!

thanks for answers

grts Hans

[F106DeltaDart]

Hey everyone,

I can rotate the plane so that the tail sits down, and it stays. If I touch the nose very lightly, it will rotate back onto the nose wheel. This is the desired balance, correct? It's ready to fly?

Interesting to read this, so my question regarding this balance method ??? is it also usable for other EDF's......!

thanks for answers

grts Hans

Not exactly. It is very dependent on how the landing gear are positioned with respect to the CG on an individual airframe. For the F-86, it is spot-on though!

[Mark 2]

I understand it also works well for the Avios Mig17

[timmybeetle]

Hi

OK I understand CG location...well if CG is at almost same place as main LG, than this will work. Thanks for info. Grts Hans

[Oxotnik]

Me-262, too. Or at least it’s very close to tail sitting.

[C17loadmaster]

Here is a quick video showing the FMS 2100kv “Pro” Version. I had the same motor/fan combo with the different spinner (black instead of silver) but I ended up “needing” the latest model. Even though it may just be the spinner haha. I have the one I just removed with the 100a ESC, specific to the F-86, if anyone wants to go FMS. I think it has about 4 flights on it total

Sorry about my wife yelling in the video... at least she records for me though

jim

[Phantom]

Here is a quick video showing the FMS 2100kv “Pro” Version. I had the same motor/fan combo with the different spinner (black instead of silver) but I ended up “needing” the latest model. Even though it may just be the spinner haha. I have the one I just removed with the 100a ESC, specific to the F-86, if anyone wants to go FMS. I think it has about 4 flights on it total

Sorry about my wife yelling in the video... at least she records for me though

jim

How much would you like for it?

[gooniac33]

Here is a quick video showing the FMS 2100kv “Pro” Version. I had the same motor/fan combo with the different spinner (black instead of silver) but I ended up “needing” the latest model. Even though it may just be the spinner haha. I have the one I just removed with the 100a ESC, specific to the F-86, if anyone wants to go FMS. I think it has about 4 flights on it total

Sorry about my wife yelling in the video... at least she records for me though

jim

The new platinum set up is different. But I have 2 of the 2100kv with plastic spinners waiting for homes... I think one will be in the Eflite F-18

[C17loadmaster]

The other setup I removed is past the international dateline by now. Could you see any increased performance? I didn’t disassemble the two together being as they didn’t need to be balanced, felt and sound fine. All I know is that with every change in EDF was noticeably better than the last. With some of them it was evident right away. The difference between the Pro and it’s predecessor was not as noticeable

[Kmot]

Are there any 3D print upgrade parts/files for the F-86?

[Ron1950]

yup that's the fms 2100 all the power the f86 needs... mine is the v1 not the pro but looks the same and sounds the same love it considering the stock motor could hardly get it going
